| Brand | Gigabyte |
| Model | Gigabyte Aorus GP-AP750GM |
| Series | Aorus |
| PSU Category | Full Modular |
| Type | ATX 12V 2.31 |
| Fan Size | 135mm |
| Lighting Effect | No |
| Lighting Type | Not Applicable |
| Zero RPM Fan Mode | Not Applicable |
| Fan Bearing | Double ball bearing |
| Noise Level | 25dBA |
| Efficiency | 90% Efficiency |
| Efficiency Rating | 80 Plus Gold |
| PFC (Power Factor Correction) | Active PFC (>0.9 typical) |
| Power Good Signal | 100 - 150ms |
| Hold Up Time | >16ms at full load |
| Protections | OCP, OTP, OVP, OPP, UVP, SCP |
| Over Voltage Protection (OVP) | Yes |
| Over Power Protection (OPP) | Yes |
| Over Current Protection (OCP) | Yes |
| Over Temperature Protection (OTP) | Yes |
| Short Circuit Protection (SCP) | Yes |
| Under Voltage Protection (UVP) | Yes |
| Power Connectors | |
| ATX Main Connectors | 1 |
| EPS Connectors | 2 |
| PCIe Connectors | 4 |
| SATA Power Connectors | 6 |
| 4-Pin Peripheral Connectors | 5 |
| Floppy Connectors | 2 |
| Minimum Power (Approx.) | 675W |
| Maximum Power | 750 Watt |
| Input AC | 100 - 240Vac |
| Input Voltage | 100 - 240V |
| Input Frequency Range | 47Hz - 63Hz |
| Input Current | 10A |
| Cable Type | Flat black cables |
| MTBF | 100000 Hours |
| Form Factor | ATX |
| Dimensions | 150 x 160 x 86mm |
| Color | Black |
| Warranty | 5 Year |
