Key features of the TP-Link CPE220 2.4 GHz 300 Mbps High Power Outdoor Wireless Access Point
Specification of the TP-Link CPE220 2.4GHz 300Mbps High Power Outdoor Wireless Access Point
| Category | Details |
|---|---|
| Model | CPE220 |
| Brand | TP-Link |
| Device Type | Outdoor Wireless Access Point / CPE |
| Wireless Standard | IEEE 802.11b/g/n |
| Frequency | 2.4GHz |
| Wireless Speed | Up to 300Mbps |
| Antenna Type | Built-in Dual Polarized Directional Antenna |
| Antenna Gain | 12dBi |
| Transmit Power | Up to 27dBm (Adjustable) |
| Coverage Distance | Up to 13km+ (Point-to-Point under ideal conditions) |
| Channel Width | 20MHz / 40MHz |
| Operating Modes | AP / Client / Repeater / AP Router / AP Client Router (WISP) |
| Network Interface | 1 × 10/100Mbps Shielded Ethernet Port |
| Management System | Pharos Control |
| Management Access | Web Interface |
| Security | WPA/WPA2, WPA-PSK/WPA2-PSK |
| QoS | Supported |
| PoE Support | Passive PoE |
| PoE Power Supply | 24V Passive PoE Adapter Included |
| Power Consumption | ≤ 5W |
| Lightning Protection | 15KV ESD Protection |
| Weather Protection | Outdoor Weatherproof Enclosure |
| Mounting Type | Pole / Wall Mount |
| Operating Temperature | -30°C to +70°C |
| Dimensions | 224 × 79 × 60 mm |
| Color | White |
| Warranty | 1 Year |
The TP-Link CPE220 2.4GHz 300Mbps High Power Outdoor Wireless Access Point is a professional outdoor wireless networking device designed for long-distance point-to-point and point-to-multipoint connectivity. Built for ISP deployment, CCTV networking, campus coverage, farms, warehouses, and outdoor internet distribution, this access point combines directional antenna technology with stable long-range wireless performance.
Powered by 2.4GHz wireless technology with speeds up to 300Mbps, the CPE220 is optimized for outdoor wireless transmission and stable connectivity over extended distances. It supports IEEE 802.11b/g/n standards and is suitable for environments where reliable outdoor coverage is required.
One of its major highlights is the built-in 12dBi 2×2 dual-polarized directional MIMO antenna, engineered to improve signal concentration and reduce interference. This directional design helps deliver stronger and more focused wireless connections for outdoor deployments.
The device supports long-range wireless transmission exceeding 13km under optimized conditions, making it suitable for connecting remote locations, CCTV backhaul systems, and wireless bridge installations. It also features TP-Link Pharos MAXtream TDMA technology, which improves throughput efficiency and reduces network congestion in multi-device deployments.
For flexible deployment, the CPE220 supports multiple operating modes including:
These modes allow the device to adapt to different networking scenarios without requiring additional hardware.
Installation is simplified with Passive PoE support, allowing power and data transmission through Ethernet with cable deployment up to approximately 60 meters. The outdoor enclosure is designed with weather resistance, lightning protection, and ESD protection for dependable operation in challenging environments.
The latest price of the TP-Link CPE220 2.4GHz 300Mbps High Power Outdoor Wireless Access Point price in Bangladesh is 8200 BDT. You can buy the TP-Link CPE220 2.4GHz 300Mbps High Power Outdoor Wireless Access Point from us at the best price. You can either purchase it through our website or directly visit our office. Our Office Address: 51, Kazi Villa, 3rd Floor, Suvastu Arcade ICT Bhaban Goli, New Elephant Road, Dhaka-1205, Bangladesh. Contact Us: +88 01894-683430
