ONV-IPS33064F Gigabit 6-port industrial Ethernet switch

ONV-IPS33064F Gigabit 6-port industrial Ethernet switch

Features of the ONV-IPS33064F Gigabit 6-port industrial Ethernet switch

(Call for Price +88 018-94683430)

4× Gigabit RJ45 + 2× Gigabit SFP ports
Fanless, IP40 aluminum housing
Dual 12–48V DC power input
DIN rail mount, industrial-grade
Unmanaged, full wire-speed forwarding

Description
Reviews (0)

Description

Specification of the ONV-IPS33064F Gigabit 6-port industrial Ethernet switch

Model	ONV-IPS33064F
Interface Characteristics
Fixed Port	410/100/1000Base-T RJ45 ports (Data) 21000Base-X uplink SFP fiber ports (Data) 2 sets V+, V- redundant DC power port (5P phoenix terminal)
Ethernet Port	Port 1-4 support 10/100/1000Base-T(X) auto-sensing, full/ half duplex MDI/ MDI-X self-adaption
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP (≤100 meters) 100BASE-TX: Cat5 or later UTP (≤100 meters) 1000BASE-T: Cat5e or later UTP (≤100 meters)
Optical Fiber Port	Gigabit optical fiber port, default not include optical module (optional single-mode/ multi-mode, single fiber/ dual fiber optical module. LC)
Optical Cable/ Distance	Multi-mode: 850nm/ 0-550m, Single-mode: 1310nm/ 0-40km, 1550nm/ 0-120km
Chip Parameter
Network Protocol	IEEE 802.3 10BASE-T, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-TX, IEEE 802.3z 1000Base-X, IEEE 802.3x
Forwarding Mode	Store and Forward (Full Wire Speed)
Switching Capacity	12Gbps (non-blocking)
Forwarding Rate @64byte	8.93Mpps
MAC	2K
Buffer Memory	2M
Jumbo Frame	9.2K
LED Indicator	Power: PWR (Green), Network: Link, Link/Act (Yellow)
Power Supply
Power Consumption	Standby<5W, Full load<8W
Working Voltage	DC12-48V, 5P industrial Phoenix terminal, support anti-reverse protection.
Power Supply	No, optional 24V/24W industrial power supply
Physical Parameter
Operation TEMP/ Humidity	-40~+80°C, 5%~90% RH Non condensing
Storage TEMP/ Humidity	-40~+85°C, 5%~95% RH Non condensing
Dimension (LWH)	11910030mm
Net /Gross Weight	0.4kg / 0.5kg
Installation	Desktop, 35mm DIN Rail
Certification & Warranty
Lightning Protection	Protection level: IP40 Lightning protection: 6KV 8/20us IEC61000-4-3 (RS):10V/m (80~1000MHz) FCC Part 15/CISPR22 (EN55022): Class B IEC61000-6-2 (Common Industrial Standard) IEC61000-4-9 (Pulsed magnet field): 1000A/m IEC61000-4-10 (Damped oscillation): 30A/m 1MHz IEC61000-4-12/18 (Shockwave): CM2.5kV, DM1kV IEC61000-4-4(EFT): Power cable: ±4kV, data cable: ±2kV IEC61000-4-16 (Common-mode transmission): 30V, 300V, 1s IEC61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge IEC61000-4-6 (Radio frequency transmission): 10V(150kHz~80MHz) IEC61000-4-8 (Power frequency magnetic field): 100A/m, 1000A/m, 1s-3s IEC61000-4-5 (Surge): Power cable: CM±4kV/ DM±2kV, data cable: ±4kV
Mechanical Properties	IEC60068-2-6 (Anti Vibration), IEC60068-2-27 (Anti Shock), IEC60068-2-32 (Free Fall)
Certification	CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS
Warranty	5 years, lifelong maintenance.

ONV-IPS33064F Gigabit 6-port industrial Ethernet switch

The ONV-IPS33064F Gigabit 6-port industrial Ethernet switch is a robust 6-port industrial Ethernet switch designed for performance, longevity, and adaptability. It provides high-speed Gigabit networking for mission-critical settings. This switch is a great option for contemporary industrial automation, surveillance systems, smart transportation, and power infrastructure because of its robust industrial design and cutting-edge fiber connectivity. With its two × Mbps SFP slots and four × Mbps RJ45 ports, the ONV-IPS33064F allows for high-speed fiber and copper uplink connections. In industrial settings, this enables flexible deployment for both short- and long-distance networking requirements.

This switch is designed to withstand harsh conditions and is protected by a robust metal casing that allows it to function in temperatures ranging from -40°C to 75°C. It is made to resist the harsh circumstances present in field installations, including vibration and electromagnetic interference. The switch is truly plug-and-play, meaning it doesn’t require any configuration. It’s perfect for quick network expansions when speed and ease of use are crucial. The ONV-IPS33064F offers versatility and simplicity in a variety of installation scenarios by supporting DIN-rail and wall-mounting, whether it is installed on solid surfaces or inside industrial cabinets. This switch’s 6KV surge and lightning protection design offers superior protection against power surges, assisting in preserving steady network functioning even in electrically noisy settings. The switch’s service life and dependability are increased by the fanless design, which guarantees quiet, energy-efficient operation with less maintenance.

Overall, the ONV-IPS33064F Gigabit 6-port industrial Ethernet switch is designed to operate reliably in settings where network failure is not an option. To keep your operations operating smoothly, this switch combines high-speed data transfer, flexible connectivity, and tough durability—whether you’re replacing existing systems or creating a whole new industrial network from scratch.

What is the price of the ONV-IPS33064F Gigabit 6-port industrial Ethernet switch in Bangladesh?

The latest price of the ONV-IPS33064F Gigabit 6-port industrial Ethernet switch is (Call for Price +88 018-94683430). You can buy the ONV-IPS33064F Gigabit 6-port industrial Ethernet switch from us at the best price. You can either purchase it through our website or directly visit our office.
