ONV-IPS33064PFG-bt Gigabit 6-port industrial bt PoE switch

ONV-IPS33064PFG-bt Gigabit 6-port industrial bt PoE switch

Features of the ONV-IPS33064PFG-bt Gigabit 6-port industrial bt PoE switch

(Call for Price +88 018-94683430)

Ports: 5× Gigabit RJ45 (4× PoE) + 1× Gigabit SFP
PoE Standard: IEEE 802.3af/at/bt, up to 90W per port
Industrial Grade: -40°C to 75°C, rugged metal casing
Power Input: Dual DC 48-57V
Design: Fanless, DIN-rail mounting

Description
Reviews (0)

Description

Specification of the ONV-IPS33064PFG-bt Gigabit 6-port industrial bt PoE switch

Model	ONV-IPS33064PFG-bt
Interface Characteristics
Fixed Port	11000M uplink SFP fiber port (Data) 110/100/1000M uplink RJ45 port (Data) 4*10/100/1000M bt PoE ports (Data /Power) 2 set V+, V- redundant DC power port (5P industrial Phoenix terminal)
Ethernet Port	Port 1-4 can support 10/100/1000Base-T auto-sensing, full/ half duplex MDI/ MDI-X self-adaption
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP (≤100 meters) 100BASE-TX: Cat5 or later UTP (≤100 meters) 1000BASE-T: Cat5e or later UTP (≤100 meters)
Optical Fiber Port	Default no include optical module (optional single-mode/ multi-mode, single fiber/ dual fiber optical module. LC)
Optical Cable/ Distance	Multi-mode: 850nm/ 0-550m, Single-mode: 1310nm/ 0-40km, 1550nm/ 0-120km.
Chip Parameter
Network Protocol	IEEE 802.3 10BASE-T, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3u 1000Base-T, IEEE 802.3z 1000Base-X, IEEE 802.3x
Forwarding Mode	Store and Forward (Full Wire Speed)
Switching Capacity	12Gbps (Non-blocking)
Forwarding Rate@64byte	8.93Mpps
MAC	2K
Buffer Memory	2M
Jumbo Frame	9.2K
LED Indicator	Power: PWR (Green), Network: Link (Yellow), PoE: PoE (Green)
PoE& Power Supply
PoE Port	Port 1-4
Power Supply Pin	1/2(+) 3/6(-) 4/5(+) 7/8(-)
Max Power Per Port	90W, IEEE 802.3 af/at/bt
Power Consumption	Standby<6W, Full Load af<60W, at<120W, bt<240W
Input Voltage/ Interface	DC48-57V, 5P industrial Phoenix terminal, support anti-reverse protection.
Power Supply	No, optional 48V/240W industrial power supply
Physical Parameter
Operation Temp/ Humidity	-40~+80°C, 5%~90% RH Non condensing
Storage Temp/ Humidity	-40~+85°C, 5%~95% RH Non condensing
Dimension (LWH)	11910030mm
Net /Gross Weight	0.4kg /0.5kg
Installation	Desktop, 35mm DIN Rail
Certification& Warranty
Lightning Protection	IEC61000-4-3 (RS):10V/m (80~1000MHz) FCC Part 15/CISPR22 (EN55022): Class A IEC61000-6-2 (Common Industrial Standard) IEC61000-4-9 (Pulsed magnet field): 1000A/m IEC61000-4-10 (Damped oscillation): 30A/m 1MHz IEC61000-4-12/18 (Shockwave): CM2.5kV, DM1kV Protection level: IP40, Lightning protection: 6KV 8/20us IEC61000-4-4(EFT): Power cable: ±4kV, data cable: ±2kV IEC61000-4-16 (Common-mode transmission): 30V, 300V, 1s IEC61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge IEC61000-4-6 (Radio frequency transmission): 10V(150kHz~80MHz) IEC61000-4-8 (Power frequency magnetic field): 100A/m, 1000A/m, 1s-3s IEC61000-4-5 (Surge): Power cable: CM±4kV/ DM±2kV, data cable: ±4kV
Mechanical Properties	IEC60068-2-6 (Anti Vibration), IEC60068-2-27 (Anti Shock), IEC60068-2-32 (Free Fall)
Certification	CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class A, RoHS
Warranty	5 years, lifelong maintenance.

ONV-IPS33064PFG-bt Gigabit 6-port industrial bt PoE switch

The ONV-IPS33064PFG-bt Gigabit 6-port industrial PoE switch is a robust PoE switch of industrial quality made to deliver dependable power and data connectivity in demanding network settings. This switch guarantees a smooth and fast connection with its six ports, which include two uplink ports (one RJ45 and one SFP fiber) and four Gigabit PoE ports. This device is perfect for IP surveillance, industrial automation, and outdoor networking applications because of its strong power supply system, sophisticated lightning protection, and broad temperature tolerance.

With its non-blocking 12Gbps switching capacity, the ONV-IPS33064PFG-bt provides high-speed gigabit connectivity, guaranteeing effective data transfer and minimal latency. It is the best option for bandwidth-intensive applications because of its store-and-forward architecture, which improves network stability by removing packet loss. The ONV-IPS33064PFG-bt is perfect for control rooms, outdoor enclosures, and industrial facilities since it provides a variety of installation options, such as desktop positioning and 35mm DIN rail mounting. It offers versatility in connecting to various network infrastructures by having both RJ45 and SFP fiber uplinks.

With an operational temperature range of -40°C to +80°C and a sturdy metal casing for protection from the weather, the ONV-IPS33064PFG-bt is made to survive tough conditions and is intended for industrial settings. With CE, FCC, and RoHS certifications, the ONV-IPS33064PFG-bt satisfies international industrial standards and guarantees dependable and high-quality performance. Long-term investment for your network infrastructure, it comes with a 5-year guarantee and lifetime maintenance support.

Overall, the ONV-IPS33064PFG-bt Gigabit 6-port industrial PoE switch offers outstanding performance, power efficiency, and dependability whether you’re establishing a high-power IP surveillance network, smart city project, or industrial automation system.
