ONV-IPS33032FS Gigabit 3-port industrial Ethernet switch

Gigabit 3-port industrial Ethernet switch

Features of the Gigabit 3-port industrial Ethernet switch

(Call for Price +88 018-94683430)

Ports: 2× Gigabit RJ45 + 1× Gigabit SFP
Type: Unmanaged industrial switch
Design: IP40, fanless, aluminum case
Power: Dual 12–48V DC input
Mounting: DIN rail

Description
Reviews (0)

Description

Specification of the Gigabit 3-port industrial Ethernet switch

Model

ONV-IPS33032FS

ONV-IPS33032FS-M

ONV-IPS33032FS-A

ONV-IPS33032FS-B

Interface Characteristics
Fixed Port	1DC5521 power socket 11000Base-X SC fiber port (Data) 2*10/100/1000Base-T RJ45 ports (Data) 2 sets V+, V- redundant DC power port (5P phoenix terminal)
Ethernet Port	Port 1-2 can support 10/100/1000Base-T(X) auto-sensing, full/ half duplex MDI/ MDI-X self-adaption
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP (≤100 meters) 100BASE-TX: Cat5 or later UTP (≤100 meters) 1000BASE-T: Cat5e or later UTP (≤100 meters)
Optical Fiber Port	Default Gigabit single-mode dual fiber SC optical module (optional single-mode single fiber/ multi-mode dual fiber optical module)
Optical Cable/ Distance	Multi-mode: 850nm/ 0-550m, Single-mode: 1310nm/ 0-40km, 1550nm/ 0-120km
Chip Parameter
Network Protocol	IEEE 802.3 10BASE-T, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-TX, IEEE 802.3z 1000Base-X, IEEE 802.3x
Forwarding Mode	Store and Forward (Full Wire Speed)
Switching Capacity	10 Gbps (non-blocking)
Forwarding Rate @64byte	4.46Mpps
MAC	2K
Buffer Memory	2M
Jumbo Frame	9.2K
LED Indicator	Power: PWR (Green), Network: Link, Link/Act (Yellow)
Power Supply
Power Consumption	Standby<4W, Full load<6W
Operating Voltage	DC12-48V, 5P industrial Phoenix terminal, supports anti-reverse protection.
Power Supply	No, optional 24V/24W industrial power supply
Physical Parameter
Operation TEMP / Humidity	-40~+75°C, 5%~90% RH Non condensing
Storage TEMP / Humidity	-40~+85°C, 5%~95% RH Non condensing
Dimension (LWH)	928832mm
Net /Gross Weight	0.3kg/ 0.4kg
Installation	Desktop, 35mm DIN Rail
Certification & Warranty
Lightning Protection	Protection level: IP40 Lightning protection: 6KV 8/20us IEC61000-4-3 (RS):10V/m (80~1000MHz) FCC Part 15/CISPR22 (EN55022): Class B IEC61000-6-2 (Common Industrial Standard) IEC61000-4-9 (Pulsed magnet field): 1000A/m IEC61000-4-10 (Damped oscillation): 30A/m 1MHz IEC61000-4-12/18 (Shockwave): CM2.5kV, DM1kV IEC61000-4-4(EFT): Power cable: ±4kV, data cable: ±2kV IEC61000-4-16 (Common-mode transmission): 30V, 300V, 1s IEC61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge IEC61000-4-6 (Radio frequency transmission): 10V(150kHz~80MHz) IEC61000-4-8 (Power frequency magnetic field): 100A/m, 1000A/m, 1s-3s IEC61000-4-5 (Surge): Power cable: CM±4kV/ DM±2kV, data cable: ±4kV
Mechanical Properties	IEC60068-2-6 (Anti Vibration), IEC60068-2-27 (Anti Shock), IEC60068-2-32 (Free Fall)
Certification	CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS
Warranty	5 years, lifelong maintenance.

ONV-IPS33032FS Gigabit 3-port industrial Ethernet switch

The ONV-IPS33032FS Gigabit 3-port industrial Ethernet switch is a small, industrial-grade Gigabit 3-port Ethernet switch made to withstand harsh conditions and handle mission-critical networking requirements. With its 2 × 10/100/1000M RJ45 ports and 1 × 1000M SFP fiber port, it provides dependable and fast connectivity for applications requiring long-distance communication and stable transmission. This switch was designed with performance and durability in mind, making it perfect for applications where reliable network operation is essential, such as traffic monitoring, industrial automation, and outdoor surveillance systems.

A 1000M SFP fiber connector on the ONV-IPS33032FS supports a range of optical modules, allowing for safe and interference-free transmission up to 120km. In distributed industrial networks, it’s a great way to connect remotely to control centers, NVRs, or core switches. This switch thrives in conditions where conventional equipment fails since it is designed to function in a broad temperature range, from -40°C to +75°C. Whether installed in factories, tunnels, railroads, or outdoor enclosures, the ONV-IPS33032FS continues to operate dependably even in the face of power fluctuations, vibration, and humidity. High resistance to electrical surges, static discharge, and electromagnetic interference is ensured by the IP40-rated metal case in conjunction with strong EMC protection.

Overall, the ONV-IPS33032FS Gigabit 3-port industrial Ethernet switch is a high-speed, multipurpose industrial switch that packs long-distance fiber connection, gigabit performance, and a sturdy design into a small, dependable package. It guarantees reliable, safe, and effective network operation wherever it is deployed, making it ideal for connecting edge devices in demanding applications.
