Hikvision DS-1LN6U-SC0 CAT6 Network Cable (Solid Copper, 0.55 mm, Orange)

Hikvision DS-1LN6U-SC0 CAT6 Network Cable

• General
• Rip-Cord Yes
• CategoryCat.6
• Sheath Printing HIKVISION 4PR 23AWG 75°C U/UTP CAT6 VERIFIED TO ANSI/TIA-568-C.2 PVC ****m mm/dd/yyyy Tracing Code-HS
• Reference StandardISO/IEC11801, ANSI/TIA-568-C.2, RoHS 2.0
• Fire Resistance No
• SeparatorYes

• Conductor
• MaterialSolid-Bare Copper (99.95%)
• Diameter: 0.55 ± 0.005 mm, 23 AWG

• Insulation
• MaterialHDPE
• Diameter: 0.98 ± 0.05 mm

• Sheath Physical Properties
• Before Aging

  Tensile strength ≥ 13.5 Mpa

  Elongation ≥ 150%

• Aging Period: 100°C × 24h × 10d
• After Aging

  Tensile strength ≥ 12.5 Mpa

  Elongation ≥ 125%

• Cold Bend-20 ± 2°C × 4h, 8 × cable O.D, no visible cracks

• Electrical Characteristics(20℃)
• 1.0-250.0 MHz Impedance

  100 ± 15 Ω @ ≤ 100 MHz

  100 ± 25 Ω @100-250 MHz

• 1.0-250.0 Mhz Delay Skew≤ 45 ns/100 m
• DC Resistance≤ 9.38 Ω/100 m
• DC Conductor Resistance Unbalance≤ 5.0%
• Package Dimension 400 mm (W) × 400 mm (H) × 240 mm (D) (15.75″ × 15.75″ × 9.45″)
• Weight12.3 ± 0.5 kg
• Cable Length(305 ± 1.5) m
• Ambient Temperature-20°C to 75°C (-4°F to 167°F)
• Operating Voltage: 60 V
• Sheath
• Thickness: 0.50 ± 0.10 mm
• Material PVC
• Color Orange
• Diameter6.00 ± 0.30 m
