ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter

Description

The ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter is a high-performance networking device that allows you to connect copper and fiber optic networks. It is ideal for a wide range of applications, including security monitoring, wireless coverage, intelligent transportation, and safe cities.

FEATURE

Gigabit photoelectric Ethernet conversion transmission

◇ Support non-blocking wire-speed forwarding.

◇ Support full-duplex based on IEEE802.3x and half-duplex based on Backpressure.

◇ Support gigabit RJ45 port and gigabit fiber port combination, which enables users to flexibly build networking to meet the needs of various scenarios.

Easy to use and simple to maintain

◇ Support full-duplex/half-duplex working mode with auto-negotiation function.

◇ Automatic identification of twisted pair MDI/MDI-X cross lines and parallel lines.

◇ LED working status indication for network diagnosis and fault checking, reducing maintenance workload.

◇ Compatible with IEEE 802.3ab 1000Base-T, IEEE802.3z 1000Base-X network protocol, gigabit R45 port rate auto-negotiation.

◇ Plug and play, no configuration required, centralized power supply and centralized connection management through 2U-14 slot rack.

Stable and reliable

◇ CCC,CE, FCC, RoHS.

◇ Low power consumption, No fan, galvanized steel casing.

◇ Comply with telecommunication network access requirements, and have the telecommunications equipment network access license of the MIIT.

Feature	Specification
Model	ONV1110S-SLX-S4
Interface	11000M uplink SC/LC fiber port (Data), 410/100/1000Base-T RJ45 ports (Data)
Ethernet Port	10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP(≤100 meters), 100BASE-TX: Cat5 or later UTP(≤100 meters), 1000BASE-T: Cat5e or later UTP(≤100 meters)
Optical Fiber Port	1.25Gbps, multi-mode dual fiber LC interface, 1.25Gbps,single-mode dual fiber LC interface, 1.25Gbps,single-mode single fiber LC interface
Optical Cable/ Distance	Multi-mode: 850nm/ 0-500m, Single-mode: 1310nm/ 0- 40km, 1550nm/ 0-120km.
Network Protocol	IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE802.3x
Forwarding Mode	Store and Forward(Full Wire Speed)
Switching Capacity	10Gbps
Forwarding	Rate@64byte
MAC	2K
Buffer Memory	2M
Jumbo Frame	1632byte
LED Indicator	Power: PWR (Green) ON/OFF, Data: Link (Green) ON/OFF/Blink, Fiber: G5 (Green)ON/OFF/Blink
Power Supply	Total PWR / Input Voltage
Power Consumption	Standby<1W, Full Load<6W
Operation TEMP/ Humidity	-20°C~+55°C, 5%~90% RH Non condensing
Storage TEMP/ Humidity	-40°C~+85°C, 5%~95% RH Non condensing
Dimension	1189528mm
Net /Gross Weight	<0.3kg / <0.8kg
Installation	Desktop, Wall-mounted
Lightning Protection	Lightning protection: 4KV 8/20us, Protection level: IP30
Certification	CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS
Warranty	3 years, lifelong maintenance.

ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter

The ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter is a versatile and high-performance solution for connecting copper and fiber optic networks. It is ideal for a wide range of applications, including security monitoring, wireless coverage, intelligent transportation, and safe cities. If you are looking for a reliable and cost-effective way to improve the speed and performance of your network, the ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter is the perfect choice for you.

Applications:

The ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter is ideal for a wide range of applications, including:

• Security monitoring: The ONV 1110S-SLX-S4-A can be used to connect security cameras and other security devices to a fiber optic network. This allows you to transmit high-definition video and other data over long distances with minimal latency.
• Wireless coverage: The ONV 1110S-SLX-S4-A can be used to extend the reach of a wireless network to remote locations. This is ideal for businesses and organizations that need to provide wireless coverage in large areas, such as campuses, office buildings, and warehouses.
• Intelligent transportation: The ONV 1110S-SLX-S4-A can be used to connect traffic lights, cameras, and other intelligent transportation systems to a fiber optic network. This allows you to monitor and manage traffic flow more effectively.
• Safe cities: The ONV 1110S-SLX-S4-A can be used to build a secure and reliable network for connecting security cameras, sensors, and other devices in a safe city. This allows you to monitor and protect your city more effectively.



What is the price of the ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter in Bangladesh?

The latest price of the ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter is 6800 BDT.

You can buy this ONV ONV 1110S-SLX-S4-A 5 Port Single Mode Dual Fiber Gigabit Media Converter from us at the best price. Or You can buy it through our website or directly visit our office.

Our Office Address: 51, Kazi Villa, 3rd Floor, Suvastu Arcade ICT Bhaban Goli, New Elephant Road, Dhaka-1205, Bangladesh.

Contact Us: +88 01894-683430
