ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch

ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch

Original price was: ৳ 16,300.00.Current price is: ৳ 15,500.00.

Features of the ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch

Model – ONV-H3016PFD-250
16× Gigabit PoE Ports (250W) – Powers IP cameras, APs, and VoIP phones.
250m Long-Distance Mode – Stable power and data for remote devices.
38Gbps Switching Capacity – High-speed, lag-free performance.
2× RJ45 & 1× SFP Uplink – Flexible network expansion.
Built-in Power & 4KV Protection – Reliable and secure operation.

Description
Reviews (0)

Description

Specification of the ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch

Model	ONV-H3016PFD-250
Fixed Ports	– 16× 10/100/1000Base-T PoE ports (Data/Power) – 2× 10/100/1000Base-T uplink RJ45 ports (Data) – 1× 1000Base-X uplink SFP fiber port (Data)
Ethernet Ports	Ports 1–18 support 10/100/1000Base-T(X) auto-sensing, full/half duplex, MDI/MDI-X self-adaptation
Twisted Pair Transmission	– 10BASE-T: Cat3, 4, 5 UTP (≤250 meters) – 100BASE-TX: Cat5 or later UTP (≤100 meters) – 1000BASE-T: Cat5e or later UTP (≤100 meters)
Optical Fiber Port	Gigabit optical fiber port, default without optical module (optional single-mode/multi-mode, single fiber/dual fiber optical module, LC connector)
Optical Cable/Distance	– Multi-mode: 850nm / 0–550m – Single-mode: 1310nm / 0–40km, 1550nm / 0–120km
Functional Switch	250m: Long-distance function (default off; to enable, switch to ON). When enabled, ports 9–16 support 10Mbps/250m transmission and PoE watchdog function.
Network Protocols	IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE802.3x
Forwarding Mode	Store and Forward (Full Wire Speed)
Switching Capacity	38Gbps (Non-blocking)
Forwarding Rate @64byte	28.27Mpps
MAC Address Table	4K
Buffer Memory	4M
Jumbo Frame	9.2K
LED Indicators	– Power: PWR (Green) – Network: Link (Green) – PoE: PoE (Red) – Functional switch: 100m/250m (Green)
PoE Ports	Ports 1–16
PoE Power Supply Pins	1/2(+) 3/6(-)
Max Power per Port	30W, PoE+
Total Power/Input Voltage	250W / AC100–240V
Power Consumption	– Standby: <5W – Full load: <250W
Power Supply	Built-in power supply, AC100–240V 50–60Hz, 4.1A
Operating Temperature/Humidity	-20°C to +55°C, 5%–90% RH non-condensing
Storage Temperature/Humidity	-40°C to +80°C, 5%–95% RH non-condensing
Dimensions (L×W×H)	350mm × 215mm × 44mm
Net/Gross Weight	2.0kg / 2.5kg
Installation	Desktop, Rack-mounted
Lightning Protection	– Lightning protection: 4KV 8/20μs – Protection level: IP30
Certifications	CCC, CE mark (commercial), CE/LVD EN62368-1, FCC Part 15 Class B, RoHS
Warranty	1 year, lifelong maintenance

ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch

The ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch is a high-performance 16-port full Gigabit PoE switch that has superior PoE (Power over Ethernet) capabilities and is made to offer smooth network connectivity. This switch guarantees seamless data transfer for enterprise solutions, IoT applications, and surveillance networks with its 16x Gigabit PoE ports, 2x Gigabit RJ45 uplink ports, and 1x Gigabit SFP uplink port. This switch’s non-blocking 38Gbps switching capability allows for fast data transfer across all ports. It is perfect for bandwidth-intensive applications like VoIP phones, IP cameras, and wireless access points because it optimizes network traffic and minimizes packet loss through the use of store-and-forward forwarding mode. The ONV-H3016PFD-250 can power 16 connected PoE devices with a maximum of 30W per port and a total PoE budget of 250W, supporting IEEE 802.3af/at PoE standards. Even for devices positioned at great distances, dependable power and data transfer are guaranteed by the long-distance mode (250m). With an SFP fiber port and two gigabit RJ45 uplink ports, this switch provides more networking options. The SFP uplink port facilitates long-distance data transfer via optical networks by supporting both single-mode and multi-mode fiber modules.

Overall, the ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch is a strong, safe, and affordable option for smooth connectivity, Whether you’re creating a sophisticated surveillance system or updating a company network.

What is the price of the ONV-H3016PFD-250 16 Ports Full Giga 2RJ45 1SFP PoE Switch in Bangladesh?

The latest price of the ONV-H3016PFD-250 is 15500 BDT. You can buy the ONV-H3016PFD-250 from us at the best price. You can either purchase it through our website or directly visit our office.
