ONV-IPS33021PFS Gigabit 2-port industrial PoE switch

Gigabit 2-port industrial PoE switch

Features of the ONV-IPS33021PFS Gigabit 2-port industrial PoE switch

(Call for Price +88 018-94683430)

Ports: 1× Gigabit RJ45 + 1× SC Fiber
PoE Standard: IEEE 802.3af/at, up to 30W
Industrial Grade: Durable for harsh environments
Power Input: Dual DC 48-57V
Reliable Design: Compact, for industrial use

Description
Reviews (0)

Description

Specification of the Gigabit 2-port industrial PoE switch

Model

ONV-IPS33021PFS

ONV-IPS33021PFS-M

ONV-IPS33021PFS-A

ONV-IPS33021PFS-B

ONV-IPS33032PFS

ONV-IPS33032PFS-M

ONV-IPS33032PFS-A

ONV-IPS33032PFS-B

Interface Characteristics
Fixed Port	110/100/1000Base-T PoE port (Data/ Power) 11000Base-X SC fiber port (Data) 2 set V+, V- redundant DC power ports (5P industrial Phoenix terminal)	210/100/1000Base-T PoE ports (Data/ Power) 11000Base-X SC fiber port (Data) 2 set V+, V- redundant DC power ports (5P industrial Phoenix terminal)
Ethernet Port	Port 1/ 1-2 can support10/100/1000Base-T(X) auto-sensing, full/ half duplex MDI/ MDI-X self-adaption
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP (≤100 meters) 100BASE-TX: Cat5 or later UTP (≤100 meters) 1000BASE-T: Cat5e or later UTP (≤100 meters)
Optical Fiber Port	Gigabit single-mode dual fiber SC optical module. (optional single-mode single fiber/ multi-mode dual fiber optical module)
Optical Cable/ Distance	Multi-mode: 850nm/ 0-550m, Single-mode: 1310nm/ 0-40km, 1550nm/ 0-120km
Chip Parameter
Network Protocol	IEEE 802.3 10BASE-T, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-X, IEEE 802.3x
Forwarding Mode	Store and Forward (Full Wire Speed)
Switching Capacity	12Gbps (non-blocking)
Forwarding Rate@64byte	2.98Mpps	4.46Mpps
MAC	2K
Buffer Memory	2M
Jumbo Frame	9.2K
LED Indicator	Power: PWR (Green), Network: Link, Link/Act (Yellow), PoE: PoE (Green)
PoE& Power Supply
PoE Port	Port 1	Port 1-2
Power Supply Pin	1/2 (+) 3/6 (-)
Power Consumption	Standby<4W, Full load<32W	Standby<5W, Full load<60W
Input Voltage/ Interface	DC48-57V, 5P industrial Phoenix terminal, support anti-reverse protection.
Power Supply	No, optional 48V/36W or 48V/60W industrial power supply
Physical Parameter
Operation Temp/ Humidity	-40~+75°C, 5%~90% RH Non condensing
Storage Temp/ Humidity	-40~+85°C, 5%~95% RH Non condensing
Dimension	928832mm
Net /Gross Weight	0.3kg/ 0.4kg
Installation	Desktop, 35mm DIN Rail
Certification& Warranty
Lightning Protection	IEC61000-4-3 (RS):10V/m (80~1000MHz) FCC Part 15/CISPR22 (EN55022): Class A IEC61000-6-2 (Common Industrial Standard) IEC61000-4-9 (Pulsed magnet field): 1000A/m IEC61000-4-10 (Damped oscillation): 30A/m, 1MHz IEC61000-4-12/18 (Shockwave): CM 2.5kV, DM 1kV Protection level: IP40, Lightning protection: 6KV 8/20us IEC61000-4-4(EFT): Power cable: ±4kV, Data cable: ±2kV IEC61000-4-16 (Common-mode transmission): 30V, 300V, 1s IEC61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge IEC61000-4-6 (Radio frequency transmission): 10V(150kHz~80MHz) IEC61000-4-8 (Power frequency magnetic field): 100A/m, 1000A/m, 1s-3s IEC61000-4-5 (Surge): Power cable: CM±4kV/ DM±2kV, Data cable: ±4kV
Mechanical Properties	IEC60068-2-6 (Anti Vibration), IEC60068-2-32 (Free Fall), IEC60068-2-27 (Anti Shock)
Certification	CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class A, RoHS
Warranty	5 years, lifelong maintenance.

ONV-IPS33021PFS Gigabit 2-port industrial PoE switch

The ONV-IPS33021PFS Gigabit 2-port industrial PoE switch is a high-performance industrial PoE switch made for challenging environments that require dependable and effective network connectivity. This switch guarantees reliable long-distance connectivity with one 1000Base-X SC fiber port and one 10/100/1000Base-T PoE port for data and power transmission. Additionally, it has two sets of V+ and V- redundant DC power ports, which improve redundancy and dependability. The device provides smooth data transfer at full wire speed with a switching capacity of 12 Gbps and support for IEEE 802.3 network protocols. Minimal packet loss is guaranteed by the store-and-forward forwarding mode, and network performance is maximized with a 2K MAC address table and 2M buffer RAM. Furthermore, the device is appropriate for high-bandwidth applications because it supports jumbo frames up to 9.2K. Stable power delivery is provided by the PoE port’s 1/2 (+), 3/6 (-) power supply pin arrangement. The unit is perfect for industrial environments because it can function in a broad temperature range of -40°C to +75°C. It is lightweight (0.3 kg), small (92 x 88 x 32 mm), and may be installed on a desktop or DIN rail for simple deployment.

Overall, the ONV-IPS33021PFS Gigabit 2-port industrial PoE switch satisfies strict safety and quality criteria and is certified by CCC, CE, FCC, and RoHS. Durability in challenging circumstances is ensured by its 6KV lightning protection, anti-vibration, and anti-shock resistance. This switch is dependable for mission-critical networking requirements and comes with a 5-year guarantee and lifetime maintenance.
