| Device | Specification |
|---|---|
| Image Sensor | 1/2.7” CMOS |
| Max. Resolution | 2304×1296 |
| Lens | f2.8 mm / F1.6 |
| Viewing Angle | 112˚ (Diagonal) |
| Min Illumination | 0.01 Lux (IR LED off), 0 Lux (IR LED on) |
| Shutter Speed | AUTO, 1/25s ~ 1/100000s |
| IR LED | 18 units |
| IR Effective Distance | Up to 30 meters |
| Day / Night | YES |
| WDR Mode | DWDR |
| RTC (real-time clock) | YES |
| Video | |
| Compression | H265 / H.264 |
| Video Resolution | Main Stream 3MP (2304x1296) / 2MP (1080P) / 720P / D1 <br> Sub Stream D1 /VGA/640x360/CCIF |
| Frame Rate | 3MP @ 25FPS / 2MP @ 30FPS |
| Video Profile | High profile main profile / Base profile |
| Multiple Video Streaming | 2 streams |
| Bitrate Control | 32Kbps - 8Mbps, VBR/CBR |
| Image Enhancement | DWDR, HLC, 2D DNR, 3D DNR, AWB and AGC |
| Day / Night Switch | Auto / Color / (B/W) / Timing |
| Forced Anti-flicker | YES |
| White Balance | Auto / Manual |
| Privacy Mask | YES |
| Text Overlay | YES |
| OSD Title Location/font size / text configurable; text input (English & Chinese characters) and image upload (BMP) supported | |
| Audio | |
| Microphone built-in | YES |
| Encoding | G.711-u / G.711-a |
| Audio Adjustment | YES |
