| Network | |
|---|---|
| LAN Port | YES |
| LAN Speed | 10/100 Based-T Ethernet |
| Supported Protocols | DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP, IPv4, Bonjour, UPnP, DNS, UDP, IGMP, QoS, SNMP |
| ONVIF Compatible | YES (Profile S) |
| Number of Online Users | 10 |
| Security | (1) Multiple user access levels with passwords; (2) IP address filtering; (3) Digest authentication |
| Remote Access | (1) Internet Explorer on the Windows operating system; (2) CMS Lite, 32-bit CMS software for the Windows operating system; (3) EagleEyes on iOS & Android mobile devices |
| Video | |
| Network Compression | H.264 (Main Profile) / MJPEG |
| Video Resolution | 1920 x 1080, 1280 x 720, 720 x 480 / 352 x 240 |
| Frame Rate | 30fps |
| Multiple Video Streaming | 2 (H.264, MJPEG) |
| General | |
| Image Sensor | 1/2.7" CMOS image sensor |
| Min Illumination | 0.1 Lux / F1.6 (Wide) ~ F2.8 (Tele), 0 Lux (IR LED ON) |
| Shutter Speed | 1/2 to 1/10,000 sec |
| S/N Ratio | More than 48dB (AGC off) |
| Lens | motorized f2.8 ~ f8.0mm / F1.6 ~ F2.8 (Auto Focus) |
| Viewing Angle | Wide: 104° (Horizontal) / 56° (Vertical) / 126° (Diagonal) Tele: 57° (horizontal)/32° (vertical)/65° (Diagonal) |
| IR LED | 4 Units |
| IR Effective Distance** | Up to 50 meters |
| IR Shift | YES |
| White Balance | ATW |
| AGE | Auto |
| IRIS Mode | AES |
| Sharpness | YES |
| POE | YES (IEEE 802.3af) |
| DWDR | YES |
| Weather-proof | IP66 |
| Operating Temperature | -25℃ ~ 50℃ |
| Operating Humidity | 90 or less relative humidity |
| Power Source (±10%) | 12V / 1A |
| Current Consumption (±10%) | 250mA (IR OFF) / 700mA (IR ON) |
| Power Consumption (±10%) | PoE & PoN: 10W; DC adapter: 8.4W |
| Net Weight (kg) | 0.94 |
| Others | |
| Mobile Surveillance | iOS & Android mobile devices |
| Motion Detection | YES |
| Event Notification | FTP / Email / SMS |
| RTC (real-time clock) | YES |
| Digital Pan / Tilt / Zoom | YES |
| Minimum Web Browsing Requirements | Intel core i3 or higher, or equivalent AMD 2GB RAM AGP graphics card, Direct Draw, 32MB RAM Windows 10, Windows 8, Windows 7, Windows Vista & Windows XP, DirectX 9.0 or later Internet Explorer 7.x or later (Windows Edge not supported) |
