| Specification | Value |
|---|---|
| Printing Method | Thermal Transfer & Direct Thermal |
| Resolution | 300 dpi (12 dots/mm) |
| Printing Speed | Max. 8 ips (203.2 mm/s) |
| Maximum Print Width | 106 mm (4.17") |
| Maximum Print Length | 11,430 mm (450") |
| Enclosure | Clamshell with double-walled plastic |
| Dimensions (W X D X H) | 226 mm (W) x 198 mm (H) x 332 mm (D) |
| Weight | 3.75 kg (8.27 lbs) |
| Label roll capacity | 127 mm (5") O.D. |
| Ribbon | 300 m long, max. O.D. 67 mm, 1" core (ink coated outside) |
| Ribbon Width | 40 mm ~ 110 mm (1.6” ~ 4.3”) |
| Processor | 32-bit RISC CPU |
| Memory | 128 MB Flash memory, 128 MB SDRAM |
| Interface | RS-232, USB 2.0, Internal Ethernet, 10/100 Mbps, USB host, GPIO (dealer option), Internal Bluetooth 4.2 (dealer option), Slot-in 802.11 a/b/g/n wireless (dealer option) |
| Power | Internal universal switching power supply, Input: AC 100-240V, 2.5A, 50-60Hz, Output: DC 24V, 5.41A, 130W |
| Display | 3.5” color TFT display, 320 x 240 pixel |
| Operation switch, button | 6 buttons (Menu, Pause/Feed, Up, Down, Left, Right) |
| Sensors | Gap transmissive sensor (position adjustable), Black mark reflective sensor (position adjustable), Ribbon encoder sensor, Ribbon end sensor, Head open sensor |
| Media Type | Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media Width | 19 ~ 112 mm (0.75” ~ 4.4”) |
| Media thickness | 0.055 ~ 0.254 mm (2.17 ~ 10 mil) |
