| Feature | Specification |
|---|---|
| HDMI port | 4 Input |
| USB port | 1 (Mouse in) |
| Input | 4:2:2 16bit HDMI YUV |
| Output | 4:2:2 16bit |
| BNC SDI | With Mouse Control |
| Video | 1080P/60fps (only) |
| HDMI Resolution | Audio 48Khz |
| SDI | 1080P/60fps |
| HDMI cable | 3M |
| Maximum length SDI Cable | 70M/RG6 |
| USB cable | 3M |
| LED Indications | YES |
| Power Supply | (±10%) 12V |
| Version of HDMI specification | HDMI 1.4 |
| HDMI Plug-and-play support | YES |
| Operating Temperature | 0°C ~40°C (50°F~104°F) |
| OSD sequence configuration | YES |
| Monitor Display | Quad / Full Screen |
| HDMI video output resolution error display | YES |
Avtech HDM02 HDMI Switch is a 4-input, 1-output switch that allows you to connect up to four HDMI sources to a single display. It supports resolutions up to 1080p at 60 fps and features a built-in mouse for easy control. The switch also supports OSD sequence configuration and monitor display in quad or full-screen mode.
