Specification of the Commscope Cat6 6-2111989-3 RJ45 Connector
| Brand |
CommScope |
| Model / Part Number |
|
| Category |
|
| Cable Type Compatibility |
|
| Interface |
RJ45 (8-position, 8-contact modular plug)
|
| Positions / Loaded Contacts |
8 / 8 |
| Termination Type |
IDC (Insulation Displacement Contact)
|
| Compatible Cable Jacket OD |
Minimum: 5.7 mm (0.224 in)
Maximum: 7.0 mm (0.276 in)
|
| Compatible Insulated Conductor Diameter |
Minimum: 0.89 mm (0.035 in)
Maximum: 1.09 mm (0.043 in)
|
| Compatible Conductor Gauge |
Solid: 26–23 AWG
Stranded: 26–23 AWG
|
| Contact Base Material |
|
| Contact Plating Material |
Gold plating |
| Plating Thickness |
1.27 µm |
| Housing / Plug Material |
Glass-filled polycarbonate body
|
| Shield / Plug Shell Material |
Stainless steel base
Nickel plating on shield
|
| Plug Insertion Life |
Minimum 750 mating cycles
|
| Insulation Resistance |
|
| Operating Temperature Range |
-10 °C to +60 °C (+14 °F to +140 °F)
|
| Agency / Safety Standard |
UL 1863 |
| Packaging Quantity |
|
Commscope Cat6 6-2111989-3 RJ45 Connector
The Commscope Cat6 6-2111989-3 RJ45
Connector is a premium-grade modular plug designed for high-speed and reliable network connections. Built to meet the performance standards of Category 6 cabling, this connector ensures superior data transmission and minimal signal loss, making it ideal for professional and commercial installations. Its robust shielded design provides excellent protection against electromagnetic interference (EMI) and crosstalk, ensuring a stable and secure connection even in demanding network environments.
Crafted from high-quality materials, the 6-2111989-3 connector features gold-plated contacts that enhance conductivity and durability while reducing the risk of corrosion over time. It supports both solid and stranded cables, allowing flexible installation options across different network setups. The toolless termination and user-friendly design make the installation process quick and efficient, reducing setup time without compromising performance.
Whether used for data centers, enterprise networks, or structured cabling systems, the
Commscope Cat6 6-2111989-3 RJ45 Connector delivers exceptional reliability, long-lasting performance, and consistent signal integrity. It is an excellent choice for technicians and network professionals who demand precision and quality in every connection.
What is the price of the Commscope Cat6 6-2111989-3 RJ45 Connector in Bangladesh?
The latest price of the Commscope Cat6 6-2111989-3 RJ45 Connector in Bangladesh is
30 BDT. You can buy the Commscope Cat6 6-2111989-3 RJ45 Connector from us at the best price. You can either buy it through our
website or directly visit our office.
