| Feature | Spec |
|---|---|
| Network standards | IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/ IEEE 802.3af/IEEE 802.3at |
| LED Indicator | 16 * Link/Act LEDs, 2 * SFP LED, 1 * PoE-MAX LED, 1 * Power LED |
| Interfaces | 16*10/100/1000 Base-T ports(Data/Power) |
| Transmission media | Recommended: CAT5/5e UTP or better |
| Fan quantity | 1 |
| Dimension | 440178.844mm |
| Level of protection | Lightning protection for ports: 6kV, Lightning protection for power: 6kV, ESD: Air discharge: ±10kV, Contact discharge: ±8kV |
| Forwarding mode | Store-and-forward |
| Switch capacity | 36bps |
| Packet forwarding rate | 26.8Mpps |
| Buffer | 2M |
| MAC address table | 8K |
| PoE budget | Single port: AF: 15.4W, AT: 30W, Whole device: 230W |
| Input voltage | 100-240V AC 50/60Hz |
| Mounting | Desktop mounting: support, Wall mounting: support, Rack mounting : support |
| Environment | Operating Temperature: 0℃~45℃, Storage Temperature: -40℃~70℃, Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing |
| Certification | FCC、CE、RoHS |
