| Feature | Spec |
|---|---|
| Network standards | IEEE802.3、 IEEE802.3u、 IEEE802.3ab、 IEEE802.3z、 IEEE802.3x、 IEEE802.3af/at、IEEE802.1p、IEEE802.1q、 IEEE802.1w、 IEEE802.1d、 IEEE802.1s |
| LED Indicator | 1Link/Act or PoE LED indicator, 1Link/1Link/Act mode converting LED indicator, 1PoE mode converting LED indicator, 1PoE Max LED indicator, 1Power LED indicator, 1*SYS LED indicator |
| Interfaces | 28* 10/100/1000 Base-T Ethernet ports, 41000 Base-X SFP ports, 1*Console port |
| Transmission media | Recommended: CAT5/5e UTP or better |
| Fan quantity | 2 |
| Level of protection | Lightning protection for ports: 6kV, Lightning protection for power: 6kV, ESD: Air discharge: ±10kV, Contact discharge: ±8kV |
| Forwarding mode | Store-and-forward |
| Switch capacity | 56Gbps |
| Packet forwarding rate | 41.70Mpps |
| Buffer | 12Mb |
| MAC address table | 16K |
| Jumbo frame | 10K |
| PoE power supply management | Support |
| PoE budget | Single port: AF: 15.4W, AT: 30W, Whole device: 370W |
| Input voltage | 100-240V AC 50/60Hz |
| Power consumption | Full load: ＜432W, Empty load: ＜23W |
| Dimension | 440.0mmx284.0mmx44.0mm |
| Mounting | Desktop mounting: support, Wall mounting: support, Rack mounting:non-support |
| Energy Efficient | Support |
| Environment | Operating temperature: 0°C - 45℃, Storage temperature: -40°C - 70°C, Operating humidity: (10% - 90%) RH, non-condensing, Storage humidity: (5% - 90%) RH, non-condensing |
| Certification | FCC、CE、RoHS |
