| Feature | Specification |
|---|---|
| Model | ASUS TUF GAMING X670E-PLUS |
| CPU | AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors |
| Memory | 4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory |
| Graphics | 1 x DisplayPort, 1 x HDMI® port |
| Expansion slots | 1 x PCIe 5.0 x16 slot, 1 x PCIe 4.0 x16 slot (supports x4 mode), 1 x PCIe 4.0 x4 slot |
| Storage | 4 x M.2 slots, 4 x SATA 6Gb/s ports |
| Special features | TUF PROTECTION, ASUS Q-Design, ASUS Thermal Solution, ASUS EZ DIY, AURA Sync |
| Ethernet | 1 x Realtek 2.5Gb Ethernet |
| USB | Rear USB (Total 10 ports): 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C®), 5 x USB 3.2 Gen 1 ports (5 x Type-A); Front USB (Total 9 ports): 1 x USB 3.2 Gen 2 connector (supports USB Type-C®), 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports, 3 x USB 2.0 headers support additional 6 USB 2.0 ports |
| Audio | Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC |
| Back Panel I/O Ports | 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 4 x USB 3.2 Gen 2 ports (3 x Type-A, 1 x USB Type-C®), 5 x USB 3.2 Gen 1 ports (5 x Type-A), 1 x DisplayPort, 1 x HDMI® port, 1 x Realtek 2.5Gb Ethernet port, 5 x Audio jacks, 1 x BIOS FlashBack™ button |
| Internal I/O Connector | 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 4 x 4-pin Chassis Fan headers, 1 x W_PUMP+ header, 1 x 24-pin Main Power connector, 2 x 8-pin +12V Power connectors, 4 x M.2 slots (Key M), 4 x SATA 6Gb/s ports, 1 x USB 3.2 Gen 2 connector (supports USB Type-C®), 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports, 3 x USB 2.0 headers support additional 6 USB 2.0 ports |
| Miscellaneous | 3 x Addressable Gen 2 headers, 1 x AURA RGB header, 1 x Clear CMOS header, 1 x COM Port header, 1 x Front Panel Audio header (AAFP), 1 x 20-3 pin System Panel header with Chassis intrude function, 1 x Thermal Sensor header, 1 x ThunderboltTM header |
| Warranty | 3 years |
