| Brand | MSI |
| Model | PRO Z790-A (Wi-Fi 6E) |
| Body Color | Black |
| Chipset Brand | Intel |
| Chipset | Intel Z790 |
| Sockets Supported | LGA1700 |
| Built-in Processor | No |
| Supported CPU | 12th, 13th, and 14th Gen Intel Core Processors |
| Generation | 12th/13th/14th |
| Memory Type | DDR5 |
| Memory MHz | Up to 5333 MHz (OC), 3200 MHz (JEDEC) |
| Memory Channel | Dual |
| Memory Slots | 4 |
| Memory Max. | 128GB |
| Optane Memory Support | No |
| Storage Interface | 6.0 Gb/s |
| M.2 Slots | 4 |
| M.2 Details | 4x M.2 (1 x PCIe 4.0 x4, supports 22110/2280/2260/2242), (1 x PCIe 4.0 x4, supports 2280/2260/2242), (2 x PCIe 4.0 x4 / SATA, supports 2280/2260/2242) |
| Graphics | Integrated (with compatible CPU) |
| Graphics Chipset | Integrated With Processor |
| Multi-GPU Support | No |
| PCI Express Slot | 3 x PCI-E x16, 1 x PCI-E x1 slot |
| Audio Chipset | Realtek ALC897 Codec |
| Audio Channels | 7.1 |
| LAN Chipset | Intel 2.5Gbps LAN |
| LAN Speed (Mbps) | 2500 |
| WiFi | Yes |
| WiFi Technology | Intel Wi-Fi 6E |
| Bluetooth | Bluetooth 5.2 |
| USB Port | 2x USB 2.0, 2x USB 3.2 Gen1 Type A, 3x USB 3.2 Gen2 Type A, 1x USB 3.2 Gen2x2 Type C |
| VGA Port | No |
| DVI Port | No |
| HDMI Port | 1 |
| DisplayPort (DP) | 1 |
| SATA Port | 6 |
| Thunderbolt | No |
| TPM Port | 1 |
| COM Port | No |
| CrossFire Support | No |
| Sli Support | No |
| Raid Support | 0, 1, 5, 10 |
| RGB Support | ARGB |
| RGB Connector | 3 x Addressable V2 RGB LED connector (JARGB_V2), 1 x RGB LED connector (JRGB) |
| Power Consumption | 70W |
| Form Factor | ATX |
| OS Support | Windows 11 or 10 |
| Warranty | 3 Year |
