| Specification | Value |
|---|---|
| Printing Method | Thermal Transfer & Direct Thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Printing Speed | Max. 10 ips (254 mm/s) |
| Maximum Print Width | 108 mm (4.25") |
| Maximum Print Length | 25,400 mm (1000") |
| Enclosure | Die-cast based print mechanism/Metal cover with large clear media view window |
| Dimensions (W X D X H) | 248 mm (W) x 274 mm (H) x 436 mm (D) |
| Weight | 9.2 kg (20.28 lbs) |
| Label roll capacity | 203.2 mm (8") O.D. |
| Ribbon | 450 m long, max. O.D. 81.3 mm, 1" core (ink coated outside or inside) |
| Ribbon Width | 40 mm ~ 110 mm (1.6” ~ 4.3”) |
| Processor | 32-bit RISC CPU |
| Memory | 128 MB Flash memory, 128 MB SDRAM |
| Interface | RS-232, USB 2.0, Internal Ethernet, 10/100 Mbps, USB host, GPIO (dealer option), Internal Bluetooth 4.2 (dealer option), Slot-in 802.11 a/b/g/n wireless (dealer option) |
| Power | Internal universal switching power supply, Input: AC 100-240V, 2.0A, 50-60Hz, Output: DC 24V, 3.75A, 90W |
| Display | 3.5” touch HVGA color LCD, 1 status indicator |
| Operation switch, button | 6 buttons (Menu, Pause/Feed, Up, Down, Left, Right) |
| Sensors | Gap transmissive sensor (position adjustable), Black mark reflective sensor (position adjustable), Ribbon encoder sensor, Ribbon end sensor, Head open sensor |
| Media Type | Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media Width | 20 ~ 120 mm (0.8” ~ 4.7”) |
| Media thickness | 0.06 ~ 0.28 mm (2.36 ~ 11 mil) |
