Description
|
Parameter |
|
|
Video |
Maximum pixel clock |
165MHz |
|
Maximum data rate |
6.75Gbps |
|
|
Resolution |
1920X1080P@60Hz; 4K@30Hz(optional model function) |
|
|
Impedance |
100Ω |
|
|
USB |
Interface |
PC: Type B USB interface; connect to pc;
K/M: connect USB keyboard and mouse; |
|
USB Signal |
HID Signal |
|
|
IR |
Interface |
3.5mm seat |
|
Signal direction |
Unidirectional |
|
|
IR frequency |
20-60kHz |
|
|
Audio |
Interface |
3.5mm seat |
|
Signal model |
Embedded unidirectional stereo |
|
|
Fiber |
Interface |
SC/FC |
|
Fiber Model |
Single mode |
|
|
wavelength |
Single mode 1310nm；1550nm |
|
|
bandwidth |
6.25Gbps |
|
|
Transmission distance |
Default standard 20KM, MAX up to 80KM |
|
|
Other |
Power supply |
The power adapter: DC 5V/1A |
|
Power dissipation |
MAX 3W |
|
|
Temperature |
Operating: -5℃ ~ +70℃ |
|
|
Humidity |
Operating: 5% ~ 90% |
|
|
Dimension |
97*73*26mm |
|
