| Mode | TVI, CVI, AHD & CVBS |
| Image Sensor | 1/ 2.5” CMOS image sensor |
| Effective Resolution | 2560 (H) x 1920 (V) |
| Video Transmission Rate | 5MP @ 20fps |
| Min. Illumination | 0.1 Lux / F1.8, 0 Lux (IR LED ON) |
| S/N Ratio | More than 48dB (AGC OFF) |
| Shutter Speed | 1/30 (1/25) sec ~ 1/ 60000 (1/ 50000) sec |
| Lens | f3.6mm / F1.8 f2.8mm / F1.8 |
| Viewing Angle | 96° (Horizontal), 50° (Vertical), and 116° (Diagonal) 100° (Horizontal), 52° (Vertical), and 121° (Diagonal) |
| IR LED Number | 2 units |
| IR Effective Range | Up to 50 meters |
| IR Shift | YES |
| Day & Night Mode | YES |
| Noise Reduction | YES |
| IRIS Mode | AES |
| White Balance | Auto |
| AGC | Auto |
| Sharpness | Adjustable |
| Flickerless | 50HZ, 60HZ / OFF |
| BLC | Adjustable |
| DWDR | YES |
| IP Rating | IP66 |
| Operating Temperature | -20℃ ~ 40℃ |
| Operating Humidity | 90% or less relative humidity |
| Power Source (±10%) | DC12V / 0.5A |
| Power Consumption (±10%) | 100mA (IR LED OFF); 240mA (IR LED ON) |
| Net Weight (Kg) | 0.36 |
| Optional Peripherals | Junction Box (AVA456-WBKT / AVA456-WHKT) |
