Key Features of the Hikvision DS-3WR12C AC1200 Wireless Router
Specification of the Hikvision DS-3WR12C AC1200 Wireless Router
| General | |
| Product Dimension (W × H × D) | 248.40 mm × 154.80 mm × 213.34 mm (9.78" × 6.09" × 8.40") |
| Package Dimension (W × H × D) | 306 mm × 290 mm × 59 mm (12.05" × 11.42" × 2.32") |
| Net Weight | 0.222 kg (0.489 lb) |
| Packing List | Wireless Router × 1, Ethernet Cable × 1, Quick Installation Guide × 1 |
| Packing Method | Single Pack |
| Working Temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Working Humidity | 10% to 90% RH (Non-Condensing) |
| Storage Temperature | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉) |
| Storage Humidity | 5% to 90% RH (Non-Condensing) |
| Installation Mode | Desktop Installation |
| Max. Power Consumption | ≤ 9 W |
| Gross Weight | 0.722 kg (1.592 lb) |
| Wireless Parameter | |
| Data Rate | ≤ 1167 Mbps |
| 2.4 GHz: 300 Mbps | |
| 5 GHz: 867 Mbps | |
| Wireless Standard | IEEE 802.11/a/n/ac wave 2 @ 5GHz, IEEE 802.11b/g/n @ 2.4GHz |
| Working Frequency Band | 2.4 GHz, 5 GHz |
| Transmitting Power (CE) | < 20 dBm (2.4G), < 23 dBm (5G) |
| Wireless Performance | 4 × 4 MU-MIMO supported, Beamforming supported |
| Receiving Sensitivity | 58 ± 2 dB @ AC80-MCS9, 84 ± 2 dB @ AC80-MCS0 |
| Antenna | 4 High Gain Antennas |
| Operating Frequency | 2.4 GHz: US/2412-2472 MHz (CH1-CH13), 5 GHz: US/5180-5240 MHz (CH36-CH48), 5 GHz: US/5740-5805 MHz (CH149-CH161) |
| EIRP Power (Max.) | 2.4 GHz: 19.86 dBm, 5 GHz: 22.96 dBm |
| Hardware Parameter | |
| Network Interface | 1 × 10/100Mbps WAN Port, 3 × 10/100Mbps LAN Ports |
| LED Indicator | LED Indicator |
| Reset | Reset Button |
| Power Supply Method | 9 VDC, 1 A Power Adapter Power Supply |
| Power Specifications | 9 VDC, 1 A |
| Software Functions | |
| Application Function | Wireless Router Mode, Wireless Repeater Mode, Client + AP, WISP, and AP Mode supported |
| DHCP Server Supported | |
| Guest Network Configuration Supported | |
| Signal Adjustment Supported | |
| WiFi Schedule Supported | |
| Security Mode | WPA-PSK, WPA2-PSK, WPA, and WPA2 Supported |
| Security Mechanism | Hide SSID |
| Management Method | Web |
| Upgrade | Web Update and Upgrade |
| System Log | System Log |
The Hikvision DS-3WR12C AC1200 Wireless Router is built for those who need fast, stable, and reliable internet at home or in a small office. With dual-band functionality, it provides smooth connectivity across multiple devices. The 2.4 GHz band delivers up to 300 Mbps, making it perfect for everyday tasks like browsing, emailing, and using smart home devices. Meanwhile, the 5 GHz band offers speeds of 867 Mbps, ideal for activities that require higher bandwidth, such as streaming in HD, online gaming, and video conferencing. Combined, this router delivers speeds of up to 1167 Mbps, ensuring seamless performance without lag or buffering.
Equipped with four high-gain antennas, the DS-3WR12C extends Wi-Fi coverage, reducing dead zones and maintaining a strong connection throughout your space. Advanced MU-MIMO technology allows multiple devices to connect simultaneously without slowing down the network, making it an excellent choice for households or offices with heavy internet usage. Beamforming technology further enhances the signal, directing it precisely toward connected devices rather than broadcasting it randomly. This results in a stronger, more reliable connection even in larger spaces.
The router features one 10/100Mbps WAN port and three 10/100Mbps LAN ports, making it easy to connect wired devices such as PCs, smart TVs, and gaming consoles. Whether setting up a home office, a gaming station, or a streaming hub, the DS-3WR12C ensures that wired connections remain just as stable as wireless ones.
Security is a priority, and this router comes with WPA-PSK, WPA2-PSK, and WPA encryption to keep your network protected from unauthorized access. The option to hide the SSID adds another layer of security, preventing outsiders from even detecting your network. With the web-based management system, users can easily customize network settings, update firmware, and monitor connected devices in just a few clicks.
For those who need flexibility, the DS-3WR12C supports multiple operating modes, including Wireless Router Mode, Repeater Mode, Client + AP, WISP, and AP Mode. This allows users to configure the router based on their specific network requirements, whether extending an existing network, creating a new one, or optimizing signal strength in certain areas.
Despite its powerful performance, this router is designed with efficiency in mind, consuming less than 9W of power. It also features a compact desktop-friendly design, making it easy to place anywhere without taking up too much space. Built to withstand varying environmental conditions, it operates smoothly within temperatures ranging from 0°C to 40°C and humidity levels between 10% to 90% RH (non-condensing).
With its high-speed performance, extended coverage, strong security, and flexible network modes, the Hikvision DS-3WR12C AC1200 Wireless Router is a great choice for anyone looking to upgrade their internet experience. Whether you need a reliable connection for work, entertainment, or everyday browsing, this router ensures you stay connected without interruptions.
The latest price of the Hikvision DS-3WR12C AC1200 Wireless Router is 2120 BDT. You can buy this Hikvision DS-3WR12C AC1200 Wireless Router from us at the best price. You can either buy it through our website or directly visit our office. Our Office Address: 51, Kazi Villa, 3rd Floor, Suvastu Arcade ICT Bhaban Goli, New Elephant Road, Dhaka-1205, Bangladesh. Contact Us: +88 01894-683430
